DSA 554 3.0 Spatio-temporal Data Analysis

Time Series Analysis Using Python

Loading packages

import pandas as pd
import plotnine as p9
from plotnine import *
from plotnine.data import *
import numpy as np

Working with Built-in Data Set

`economics` data set

economics

	date	pce	pop	psavert	uempmed	unemploy
0	1967-07-01	507.4	198712	12.5	4.5	2944
1	1967-08-01	510.5	198911	12.5	4.7	2945
2	1967-09-01	516.3	199113	11.7	4.6	2958
3	1967-10-01	512.9	199311	12.5	4.9	3143
4	1967-11-01	518.1	199498	12.5	4.7	3066
...	...	...	...	...	...	...
569	2014-12-01	12122.0	320201	5.0	12.6	8688
570	2015-01-01	12080.8	320367	5.5	13.4	8979
571	2015-02-01	12095.9	320534	5.7	13.1	8705
572	2015-03-01	12161.5	320707	5.2	12.2	8575
573	2015-04-01	12158.9	320887	5.6	11.7	8549

574 rows × 6 columns

economics.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 574 entries, 0 to 573
Data columns (total 6 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   date      574 non-null    datetime64[ns]
 1   pce       574 non-null    float64
 2   pop       574 non-null    int64
 3   psavert   574 non-null    float64
 4   uempmed   574 non-null    float64
 5   unemploy  574 non-null    int64
dtypes: datetime64[ns](1), float64(3), int64(2)
memory usage: 27.0 KB

Time Series Data Wrangling Part 1: Create new time-based variables

Task 1: Create `year` and `month` columns

economics['year'] = economics['date'].dt.year
economics['month'] = economics['date'].dt.month
economics

	date	pce	pop	psavert	uempmed	unemploy	year	month
0	1967-07-01	507.4	198712	12.5	4.5	2944	1967	7
1	1967-08-01	510.5	198911	12.5	4.7	2945	1967	8
2	1967-09-01	516.3	199113	11.7	4.6	2958	1967	9
3	1967-10-01	512.9	199311	12.5	4.9	3143	1967	10
4	1967-11-01	518.1	199498	12.5	4.7	3066	1967	11
...	...	...	...	...	...	...	...	...
569	2014-12-01	12122.0	320201	5.0	12.6	8688	2014	12
570	2015-01-01	12080.8	320367	5.5	13.4	8979	2015	1
571	2015-02-01	12095.9	320534	5.7	13.1	8705	2015	2
572	2015-03-01	12161.5	320707	5.2	12.2	8575	2015	3
573	2015-04-01	12158.9	320887	5.6	11.7	8549	2015	4

574 rows × 8 columns

Time Series Visualization

Time Series Plots

Plot 1: Dot chart

%matplotlib inline
(
    ggplot(economics, aes(x='date', y='uempmed'))
    + geom_point() # line plot
    + labs(x='date', y='median duration of unemployment, in week')
)

Plot 2: Line chart

%matplotlib inline
(
    ggplot(economics, aes(x='date', y='uempmed')) + geom_line()
)

Plot 3: Dot and Line Chart

%matplotlib inline
(
    ggplot(economics, aes(x='date', y='uempmed')) + geom_line() + geom_point()
)

Change Point Size

ggplot(economics, aes(x='date', y='uempmed')) + geom_line() + geom_point(size=0.3)

Change Point Colour

ggplot(economics, aes(x='date', y='uempmed')) + geom_line() + geom_point(size=0.3, colour="blue")

Question 1: Which is the best? Plot1, Plot 2, or Plot 3

Seasonal plots

Seasonal plot with lines

ggplot(economics, aes(x='month', y='uempmed', color='year'))+geom_point()

Seasonal plot with lines

ggplot(economics, aes(x='month', y='uempmed',group='year' ,color='year'))+geom_point()+geom_line()

Question 2: What potential issues or areas for improvement can you identify in the plot?

Fix x-axis

ggplot(economics, aes(x='month', y='uempmed',group='year' ,color='year'))+geom_point()+geom_line()+scale_x_continuous(breaks=range(1, 13))

Add titles

    ggplot(economics, aes(x='month', y='uempmed', group='year', color='year')) + geom_point() + geom_line() + scale_x_continuous(breaks=range(1, 13)) +  labs(
        title="Median Duration of Unemployment by Month",
        x="Month",
        y="Unemployment",
        color="Year"
    ) + theme_minimal()

Box-plots: monthly variation

    ggplot(economics, aes(x='month', y='uempmed', group='month', color='month')) + geom_boxplot() + scale_x_continuous(breaks=range(1, 13))

Box-plots: yearly variation

    ggplot(economics, aes(x='year', y='uempmed', group='year', color='year')) + geom_boxplot()

Exercise 1

Visualize Air Passengers dataset.

Step 1: Read data

airpassenger = pd.read_csv('AirPassengers.csv')

Step 2: About the dataset

airpassenger

	Month	#Passengers
0	1949-01	112
1	1949-02	118
2	1949-03	132
3	1949-04	129
4	1949-05	121
...	...	...
139	1960-08	606
140	1960-09	508
141	1960-10	461
142	1960-11	390
143	1960-12	432

144 rows × 2 columns

airpassenger.head()

	Month	#Passengers
0	1949-01	112
1	1949-02	118
2	1949-03	132
3	1949-04	129
4	1949-05	121

airpassenger.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 144 entries, 0 to 143
Data columns (total 2 columns):
 #   Column       Non-Null Count  Dtype
---  ------       --------------  -----
 0   Month        144 non-null    object
 1   #Passengers  144 non-null    int64
dtypes: int64(1), object(1)
memory usage: 2.4+ KB

Time Series Data Wrangling Part 2: Type Convertions

Cross Sectional Dataset

import pandas as pd
data = {
  "ID": [1, 2, 3],
  "calories": [420, 380, 390]

}

#load data into a DataFrame object:
dfc = pd.DataFrame(data)
dfc
dfc.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 3 entries, 0 to 2
Data columns (total 2 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   ID        3 non-null      int64
 1   calories  3 non-null      int64
dtypes: int64(2)
memory usage: 180.0 bytes

Time Series Dataset

data = {
  "Year": [2019, 2020, 2021],
  "Sales": [490, 980, 260]

}

#load data into a DataFrame object:
dft = pd.DataFrame(data)
dft
dft.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 3 entries, 0 to 2
Data columns (total 2 columns):
 #   Column  Non-Null Count  Dtype
---  ------  --------------  -----
 0   Year    3 non-null      int64
 1   Sales   3 non-null      int64
dtypes: int64(2)
memory usage: 180.0 bytes

Air Passenger Dataset

airpassenger.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 144 entries, 0 to 143
Data columns (total 2 columns):
 #   Column       Non-Null Count  Dtype
---  ------       --------------  -----
 0   Month        144 non-null    object
 1   #Passengers  144 non-null    int64
dtypes: int64(1), object(1)
memory usage: 2.4+ KB

Time Series Plot for Air Passenger Dataset

ggplot(airpassenger, aes(x='Month', y='#Passengers'))+geom_line()

C:\Users\DELL\AppData\Local\Programs\Python\Python312\Lib\site-packages\plotnine\geoms\geom_path.py:111: PlotnineWarning: geom_path: Each group consist of only one observation. Do you need to adjust the group aesthetic?

Convert to Time Column

from datetime import datetime
airpassenger['Month']= pd.to_datetime(airpassenger['Month'])
airpassenger.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 144 entries, 0 to 143
Data columns (total 2 columns):
 #   Column       Non-Null Count  Dtype
---  ------       --------------  -----
 0   Month        144 non-null    datetime64[ns]
 1   #Passengers  144 non-null    int64
dtypes: datetime64[ns](1), int64(1)
memory usage: 2.4 KB

Index - Yearly

Method 1

index1 = pd.DatetimeIndex(['2012', '2013', '2014', '2015', '2016'])
data1 = pd.Series([123, 39, 78, 52, 110], index=index1)
data1

2012-01-01    123
2013-01-01     39
2014-01-01     78
2015-01-01     52
2016-01-01    110
dtype: int64

Method 2

freq=‘AS’ for start of year

index2 = pd.date_range("2012", periods=5, freq='AS')
index2

DatetimeIndex(['2012-01-01', '2013-01-01', '2014-01-01', '2015-01-01',
               '2016-01-01'],
              dtype='datetime64[ns]', freq='AS-JAN')

data2 = pd.Series([123, 39, 78, 52, 110], index=index2)
data2

2012-01-01    123
2013-01-01     39
2014-01-01     78
2015-01-01     52
2016-01-01    110
Freq: AS-JAN, dtype: int64

Method 3

freq=‘A’ end of year frequency

index3 = pd.date_range("2012", periods=5, freq='A')
index3

DatetimeIndex(['2012-12-31', '2013-12-31', '2014-12-31', '2015-12-31',
               '2016-12-31'],
              dtype='datetime64[ns]', freq='A-DEC')

data3 = pd.Series([123, 39, 78, 52, 110], index=index3)
data3

2012-12-31    123
2013-12-31     39
2014-12-31     78
2015-12-31     52
2016-12-31    110
Freq: A-DEC, dtype: int64

Method 4

Annual indexing with arbitrary month

index4 = pd.date_range("2012", periods=5, freq='AS-NOV')
index4

DatetimeIndex(['2012-11-01', '2013-11-01', '2014-11-01', '2015-11-01',
               '2016-11-01'],
              dtype='datetime64[ns]', freq='AS-NOV')

data4 = pd.Series([123, 39, 78, 52, 110], index=index4)
data4

2012-11-01    123
2013-11-01     39
2014-11-01     78
2015-11-01     52
2016-11-01    110
Freq: AS-NOV, dtype: int64

Method 5

Year Only

index = pd.period_range('2012-01', periods=8, freq='A')
index

PeriodIndex(['2012', '2013', '2014', '2015', '2016', '2017', '2018', '2019'], dtype='period[A-DEC]')

Index - Monthly

Method 1

index = pd.period_range('2022-01', periods=8, freq='M')
index

PeriodIndex(['2022-01', '2022-02', '2022-03', '2022-04', '2022-05', '2022-06',
             '2022-07', '2022-08'],
            dtype='period[M]')

Method 2

index = pd.period_range(start='2022-01-01', end='2022-08-02', freq='M')
index

PeriodIndex(['2022-01', '2022-02', '2022-03', '2022-04', '2022-05', '2022-06',
             '2022-07', '2022-08'],
            dtype='period[M]')

Index - Quarterly

index = pd.period_range('2022-01', periods=8, freq='Q')
index

PeriodIndex(['2022Q1', '2022Q2', '2022Q3', '2022Q4', '2023Q1', '2023Q2',
             '2023Q3', '2023Q4'],
            dtype='period[Q-DEC]')

Index - Daily

index = pd.period_range('2022-01-01', periods=8, freq='D')
index

PeriodIndex(['2022-01-01', '2022-01-02', '2022-01-03', '2022-01-04',
             '2022-01-05', '2022-01-06', '2022-01-07', '2022-01-08'],
            dtype='period[D]')

Index - hourly

Method 1

Range of hourly timestamps

pd.period_range('2022-01', periods=8, freq='H')

PeriodIndex(['2022-01-01 00:00', '2022-01-01 01:00', '2022-01-01 02:00',
             '2022-01-01 03:00', '2022-01-01 04:00', '2022-01-01 05:00',
             '2022-01-01 06:00', '2022-01-01 07:00'],
            dtype='period[H]')

Method 2

pd.timedelta_range(0, periods=10, freq='H')

TimedeltaIndex(['0 days 00:00:00', '0 days 01:00:00', '0 days 02:00:00',
                '0 days 03:00:00', '0 days 04:00:00', '0 days 05:00:00',
                '0 days 06:00:00', '0 days 07:00:00', '0 days 08:00:00',
                '0 days 09:00:00'],
               dtype='timedelta64[ns]', freq='H')

ACF and PACF plots

Preparing data

import pandas as pd
from matplotlib import pyplot as plt
from statsmodels.graphics.tsaplots import plot_acf, plot_pacf
# Select relevant data, index by Date
data = airpassenger[['Month', '#Passengers']].set_index(['Month'])
# Calculate the ACF (via statsmodel)
data

	#Passengers
Month
1949-01-01	112
1949-02-01	118
1949-03-01	132
1949-04-01	129
1949-05-01	121
...	...
1960-08-01	606
1960-09-01	508
1960-10-01	461
1960-11-01	390
1960-12-01	432

144 rows × 1 columns

ACF plot

data.info()

<class 'pandas.core.frame.DataFrame'>
DatetimeIndex: 144 entries, 1949-01-01 to 1960-12-01
Data columns (total 1 columns):
 #   Column       Non-Null Count  Dtype
---  ------       --------------  -----
 0   #Passengers  144 non-null    int64
dtypes: int64(1)
memory usage: 2.2 KB

fig, axes = plt.subplots(1, 2, figsize=(12, 5))
plot_acf(data, lags=50)
axes[0].set_title('ACF Plot')

plot_pacf(data, lags=50)
axes[1].set_title('PACF Plot')
plt.tight_layout()
plt.show()

Your turn: Obtain ACF and PACF plot for economics dataset

Generate Time Dependent Variables

Generate a sequence

%matplotlib inline
%config InlineBackend.figure_format = 'svg'
import warnings
warnings.filterwarnings('ignore')

import numpy as np
import pandas as pd
import datetime
from math import ceil
from plotnine import * # use python's ggplot2

ts = pd.date_range('1/1/2020', periods = 366) # generate 2020 all year data, sum up 366 days
ts

DatetimeIndex(['2020-01-01', '2020-01-02', '2020-01-03', '2020-01-04',
               '2020-01-05', '2020-01-06', '2020-01-07', '2020-01-08',
               '2020-01-09', '2020-01-10',
               ...
               '2020-12-22', '2020-12-23', '2020-12-24', '2020-12-25',
               '2020-12-26', '2020-12-27', '2020-12-28', '2020-12-29',
               '2020-12-30', '2020-12-31'],
              dtype='datetime64[ns]', length=366, freq='D')

convert Datetime into string

ts = pd.Series(ts).apply(str)

extract YYYY-MM-DD date

new = ts.str.split(" ", n = 1, expand = True) # extract YYYY-MM-DD date
new

	0	1
0	2020-01-01	00:00:00
1	2020-01-02	00:00:00
2	2020-01-03	00:00:00
3	2020-01-04	00:00:00
4	2020-01-05	00:00:00
...	...	...
361	2020-12-27	00:00:00
362	2020-12-28	00:00:00
363	2020-12-29	00:00:00
364	2020-12-30	00:00:00
365	2020-12-31	00:00:00

366 rows × 2 columns

ts = new[0]
ts

0      2020-01-01
1      2020-01-02
2      2020-01-03
3      2020-01-04
4      2020-01-05
          ...
361    2020-12-27
362    2020-12-28
363    2020-12-29
364    2020-12-30
365    2020-12-31
Name: 0, Length: 366, dtype: object

Slicing month from YYYY-MM-DD format

month = ts.apply(lambda x: int(x[5:7]))
month

0       1
1       1
2       1
3       1
4       1
       ..
361    12
362    12
363    12
364    12
365    12
Name: 0, Length: 366, dtype: int64

Slicing day from YYYY-MM-DD format

month = ts.apply(lambda x: int(x[8:10]))
month

0       1
1       2
2       3
3       4
4       5
       ..
361    27
362    28
363    29
364    30
365    31
Name: 0, Length: 366, dtype: int64

Loading packages

Working with Built-in Data Set

economics data set

Time Series Data Wrangling Part 1: Create new time-based variables

Task 1: Create year and month columns

Time Series Visualization

Time Series Plots

Plot 1: Dot chart

Plot 2: Line chart

Plot 3: Dot and Line Chart

Change Point Size

Change Point Colour

Question 1: Which is the best? Plot1, Plot 2, or Plot 3

Seasonal plots

Seasonal plot with lines

Seasonal plot with lines

Question 2: What potential issues or areas for improvement can you identify in the plot?

Fix x-axis

Add titles

Box-plots: monthly variation

Box-plots: yearly variation

Exercise 1

Time Series Data Wrangling Part 2: Type Convertions

Cross Sectional Dataset

Time Series Dataset

Air Passenger Dataset

Time Series Plot for Air Passenger Dataset

Convert to Time Column

Index - Yearly

Method 1

Method 2

Method 3

Method 4

Method 5

Index - Monthly

Method 1

Method 2

Index - Quarterly

Index - Daily

Index - hourly

Method 1

Method 2

ACF and PACF plots

Preparing data

ACF plot

Your turn: Obtain ACF and PACF plot for economics dataset

Generate Time Dependent Variables

Generate a sequence

convert Datetime into string

extract YYYY-MM-DD date

Slicing month from YYYY-MM-DD format

Slicing day from YYYY-MM-DD format

`economics` data set

Task 1: Create `year` and `month` columns
